Bluetooth Barcode Scanner
>
|
|
| Brand Name | YHDAA |
| Certification | CE,FCC,ROHS,IP54,FDA,SGS |
| Model Number | YHD-5700DB |
2D Barcode Scanner is an advanced and powerful scanning device that can quickly and accurately scan various barcodes. It is designed with USB/Bluetooth/2.4 Wireless scanning interface, 4mil scanning resolution, Manual/ Automatic/ Continuous scanning mode, and is compatible with multiple systems. It is capable of scanning 500scans/sec, so it can effectively save time.
2D Barcode Scanner is widely used in multiple industries such as retail, logistics, healthcare, hospitality, banking, etc. It is reliable, robust and easy to use. It not only gives accurate results, but also makes it easier to track and manage data with its advanced scanning capabilities.
|
Product Specification: YHD-5700DB 2D Wireless Bluetooth Barcode Scanner |
||
| Scanner parameters: | ||
| Transmission mode:Bluetooth/2.4G/Wired | Storage:100,000 barcodes | |
| Distance:50m/100m/1.5m | Sensor:640*480 CMOS | |
| CPU:ARM 32-bit Cortex |
Battery: 3.7V-2600mAh
|
|
| Indication:Buzzer & LED | Light aimer: 617nm LED | |
| Resolution :4mil | Anti-inference:0-100000Lux Max | |
| Decoding speed:500scans/sec | Illumination: 6500K LEDs | |
| Printing Contract :≥25% | Interface:USB,USB-COM | |
| Button life :8000,000 times | Material: ABS+PC | |
| Trigger Mode:Handheld,Continuous,Auto-Induction | ||
|
Depth Of Field |
13mil-EAN13 | 50-250mm |
| 4mil-code39 | 60-100mm | |
| 20mil-QR | 40-300mm | |
| 10mil-PDF417 | 40-280mm | |
|
Decode Capability: 1D:UPC-A,UPC-E,EAN-8,EAN-13,Code 128, Code 39,Code 93,Code 11,Interleaved 2 of 5,Matrix 2 of 5,Standard 2 of 5, Coda bar,MSI Plessey,RSS,etc. 2D: QR Code, Data Matrix,PDF417,Aztec code,Maxicode,etc. |
||
| Scanning Angle:Angle of rotation360°,inclination± 65°,declination ± 60° | ||
| Working current:3.3Vx200mA | Standby current :18uA-5mA | |
| Working time :7 to 10 days | Charging power:5V-400mA | |
| Certificate :CE,FCC,RoHS,IP54 | Drop test :2m | |
Packaging Details
Standard List: Scanner*1, Cable *1, USB Receiver*1, Manual *1, Box *1
Single Package Size: 167*80*100mm
Single Gross Weight: 0.28kg
50pcs/CTN Carton Size: 535*420*350mm
50pcs/CTN Carton G.W.:14Kg, N.W.:11Kg
A: There are DHL,Fedex,TNT, UPS.
We also can ship the goods by your shipping account or other express agent you provided.
Q2. What's the payment way ?
A: We accept Alibaba online orders, PayPal,T /T, LC, Western Union, MoneyGram.
Q3. How about your product warranty ?
A: Our officially promised warranty time is two years after delivery.
Q4. How can I get the goods ?
A: We will choost the fast , safe , and cost saving way to send goods to you.
With well packed carton by foam and plastic film to advoid goods damage.
Q5. If I come across any problem during product using ,
where I can get the support ?
A: We support you technically 24h/7.please send all your questions to us.
and we will give the professional,patient,expliantion by email or call in time.
