2D Barcode Scanner
>
|
| Brand Name | YHDAA |
| Certification | CE,FCC,ROHS,IP54,FDA,SGS |
| Model Number | YHD-5700DB |
2D Bluetooth Handheld Scanners Barcode Reader Supermarket Barcode Scanner YHD-5700DB
The bluetooth barcode scanner built to survive harsh treatment including 2 m (10 ft) drops, 1,000 1 m (3.3 ft) tumbles, working temperatures from 0°C to 40°C (32°F to 104°F) and IP54 sealing, high shock-resistant. With industry-leading 2600mah battery,super-long standby time.To create the best scanning experience, we pioneeringly combine 3 connection in use. Compatible with 2.4G Wireless connection receiver; Bluetooth Function; Wired usb connection. Easily connected with your laptop, PC, mobile phone, tablet, iphone, ipad, POS. Work with Windows XP/7/8/10, Mac OS, Windows Mobile, Android OS, iOS.
Features
● HID/SPP Mode and can switch.
● Supports Bluetooth/2.4G/Wired Mode, 3modes for option.
● Supports Handheld/Continuous/Auto-Induction , 3modes for option.
● Support over sixteen different countries' keyboard layout.
● Built-in 2600mAh battery, super-long standby time.
● Support for smart phones/tablets/computers; compatible for Windows /Android /IOS.
● It can read not only all kinds of 1D barcodes on paper but also barcodes on the mobile phone and computer screen, and it also can read 2D barcodes.
● Can be customized according to customer demand.
Technical parameter
Transmission mode : Bluetooth/2.4G/Wired
Storage : 100,000 barcodes
Distance : 50m/100m/1.5m
Sensor : 640*480 CMOS
CPU : ARM 32-bit Cortex
Battery : 3.7V-2600mAh
Indication : Buzzer & LED
Light aimer : 617nm LED
Resolution : 4mil
Anti-inference : 0-100000Lux Max
Decoding speed : 500scans/sec
Illumination : 6500K LEDs
Printing Contract : ≥25%
Interface : USB,USB-COM
Button life : 8000,000 times
Material : ABS+PC
Trigger Mode : Handheld,Continuous,Auto-Induction
Depth Of Field : 13mil-EAN13 50-250mm,4mil-code39 60-100mm,20mil-QR 40-300mm,10mil-PDF417 40-280mm
Decode Capability:
1D: UPC-A,UPC-E,EAN-8,EAN-13,Code 128,Code 39,Code 93,Code 11,Interleaved 2 of 5,Matrix 2 of 5,Standard 2 of 5,
Coda bar,MSI Plessey,RSS,etc.
2D : QR Code,Data Matrix,PDF417,Aztec code,Maxicode,etc.
Scanning angle : Angle of rotation360°,inclination± 65°,declination ± 60°
Working current : 3.3Vx200mA Standby current : 18uA-5mA
Working time : 7 to 10 days
Charging power : 5V-400mA
Certificate : CE,FCC,ROHS,IP54,FDA,SGS
Drop test : 2m
Standard List: Scanner*1, Cable *1, USB Receiver*1, Manual *1, Box *1
Single Package Size: 167*80*100mm
Single Gross Weight: 0.28kg
50pcs/CTN Carton Size: 535*420*350mm
50pcs/CTN Carton G.W.:14Kg, N.W.:11Kg
